Overview
Bake Element Wattages: 600 Broil Element Wattages: 1,750
Convection Element Wattages: 1,700 W
Cavity Capacity (cu. ft.): 1.6 cu. ft
Technical Data
Watts (W): 3,840 W
Circuit Breaker (A): 16 A
Volts (V): 208 or 240 V
Frequency (Hz): 60 Hz
Plug Type: 4 wire fixed connection
Power Cord Length (in.): 48
Dimensions and Weight
Width: 29 3/4"
Height: 19 5/8
Depth: 22 3/8"
Cutout Standard Depth: 22"
Cutout Standard Width: 28 1/2"
Cutout Standard Height: 20 1/8"
Cutout Flush Width: 30"
Cutout Flush Depth: 23 1/2"
Cutout Flush Height: 9 7/8"
Turntable Diameter (in.): 12 3/4Net
Weight (lbs): 96 lbs.
